Product Specification: |
|
| |
The valve is controlled by solenoid valve and can implement remote open & close operation to substitute electrical driven gate valve or butterfly vale.
The 600X motorized valve is a kind of waterpower operated valve that utilizes a solenoid valve as its pilot valve. It is normally used in
automatic control for water supply and drain systems and other industrial systems. It is precise and quick in its response in the process
of control and utilizes remote operations through turning on/off the management system via remote control signals. It can also replace
gate valve and butterfly valve for application in large-sized electrically operated systems because the shut-off speed of the valve is
adjustable and smooth shutoff can be realized without causing any pressure variation. This valve is small in volume and weight,
simple to maintain and repair, easy to use, safe and reliable. Both 220VAC and 24VDC can be used for the solenoid valve and you
can choose to use the constantly open or constantly closed valve according to you actual needs during a specific situation.
Pressure Rating: PN10. PN16. PN25/Class150Size Range: DN20mm-DN800mm (3/4" - 32")Test and inspection: GB/T 13927 API598 |
| |
Dimensions( mm) |
|
| |
DN |
L |
D |
D1 |
D2 |
Z-~d |
H1 |
H |
PN10 |
PN16 |
PN25 |
PN10 |
PN16 |
PN25 |
PN10 |
PN16 |
PN25 |
PN10 |
PN16 |
PN25 |
50 |
203 |
165 |
165 |
165 |
125 |
125 |
125 |
102 |
102 |
99 |
4-~18 |
4-~18 |
4-~18 |
300 |
95 |
65 |
216 |
185 |
185 |
185 |
145 |
145 |
145 |
122 |
122 |
118 |
4-~18 |
4-~18 |
8-~18 |
288 |
97 |
80 |
241 |
200 |
200 |
200 |
160 |
160 |
160 |
133 |
133 |
132 |
8-~18 |
8-~18 |
8-~18 |
310 |
109 |
100 |
292 |
220 |
220 |
235 |
180 |
180 |
190 |
158 |
158 |
156 |
8-~18 |
8-~18 |
8-~18 |
340 |
152 |
125 |
330 |
250 |
250 |
270 |
210 |
210 |
220 |
184 |
184 |
184 |
8-~18 |
8-~18 |
8-~18 |
380 |
152 |
150 |
356 |
285 |
285 |
300 |
240 |
240 |
250 |
212 |
212 |
211 |
8-~18 |
8-~18 |
8-~18 |
410 |
160 |
200 |
495 |
340 |
340 |
360 |
295 |
295 |
310 |
268 |
268 |
274 |
8-~22 |
12-~26 |
12-~26 |
440 |
220 |
250 |
622 |
395 |
405 |
425 |
350 |
355 |
370 |
320 |
320 |
330 |
12-~22 |
12-~26 |
12-~26 |
460 |
250 |
300 |
698 |
445 |
460 |
485 |
400 |
410 |
430 |
370 |
370 |
389 |
12-~2 |
12-~26 |
12-~26 |
480 |
270 |
350 |
787 |
505 |
520 |
555 |
460 |
470 |
490 |
430 |
430 |
448 |
16-~22 |
16-~26 |
16-~26 |
516 |
314 |
400 |
914 |
565 |
580 |
620 |
515 |
525 |
550 |
482 |
482 |
503 |
16-~26 |
16-~30 |
16-~30 |
560 |
340 |
450 |
978 |
615 |
640 |
670 |
565 |
585 |
600 |
532 |
545 |
548 |
20-~26 |
20-~30 |
20-~30 |
560 |
340 |
|
|
| |
Main Technical Features |
|
| |
PN |
1.0MPa |
1.6MPa |
2.5MPa |
Shell Test |
1.5MPa |
2.4MPa |
3.75MPa |
Seal Test |
1.1MPa |
1.76MPa |
2.75MPa |
Suitable Temperature |
《80oC |
Suitable Medium |
Water |
|
|
| |
7.700X Pump Control Valve |
|
| |
 |
|
| |
Product Specification: |
|
| |
The valve eliminates damaging water surges (hammer) caused when pump starts up and shuts off. The electrically activated valve
gradually opens when pump starts up, and slowly closes before the pump is switched off. The valve also operates as a slow control
check valve, preventing reverse flow and water hammer when power failure.
The 700X pump control valve is a kind of check valve intended for installation at outlets of pumps in high-rise buildings and other
water supply systems to prevent reverse flow of the medium. When the pump is about to stop water supply, the valve first shuts off slowly
by about 90% so as to avoid water hammer caused by the sudden shutdown of the pump. When the pump comes to a complete stop,
the valve then shuts off completely so as to prevent the reverse flow of water pumped out. This can effectively protect the pump and
avoid the reverse rotation caused by the impact of reverse flow. This product is an indispensable protective device at outlets of pumps.
It has a streamlined design, can realize precise turning on/off through guidance and is controlled by the solenoid valve.
Furthermore, our pump control valve is safe, reliable, effectively avoids water hammer, boasts a long service life and is easy to install
and maintain. Pressure Rating: PN10. PN16. PN25/Class150Size Range: DN20mm-DN800mm (3/4" - 32")Test and
inspection: GB/T 13927 API598 |
|
| |
Dimensions( mm) |
|
| |
DN |
50 |
65 |
80 |
100 |
125 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
L |
203 |
216 |
241 |
292 |
330 |
356 |
495 |
622 |
698 |
787 |
914 |
978 |
H1 |
160 |
180 |
200 |
270 |
310 |
320 |
370 |
430 |
480 |
525 |
580 |
635 |
H |
395 |
405 |
430 |
510 |
560 |
585 |
675 |
730 |
760 |
840 |
910 |
910 |
|
|
| |
Main Technical Features |
|
| |
PN |
1.0MPa |
1.6MPa |
2.5MPa |
Shell Test |
1.5MPa |
2.4MPa |
3.75MPa |
Seal Test |
1.1MPa |
1.76MPa |
2.75MPa |
Suitable Temperature |
《80oC |
Suitable Medium |
Water |
|
|
| |
8.800X Pressure Difference Balance Valve |
|
| |
 |
|
| |
Product Specification: |
|
| |
The 800X pressure difference balance valve is a kind of valve intended for use between the water supply part and the return water
part of an air conditioning system to balance the pressure difference |
|
| |
This valve can increase the utilization factor of a system, maintain the pressure difference at a precise constant value, and
maximally reduce the system noise and avoid damages caused to the equipment because of an excessive pressure difference.
The 800X pressure difference balance valve excels over other balance valve in the fact that it does not have an actuating mechanism,
depends entirely on its own pressure difference to realize the function of balancing the system. Accordingly, our pressure difference
balance valve saves energy and requires little installation space, thus can be regarded as an intelligent valve.
Pressure Rating: PN10. PN16. PN25/Class150Size Range: DN20mm-DN800mm (3/4" - 32")Test and inspection: GB/T 13927 API598 |
|
